TwinReverb/ProReverb/DeluxeReverb/Bassman

ﾂｲﾝﾘﾊﾞｰﾌﾞ/ﾌﾟﾛﾘﾊﾞｰﾌﾞ/ﾃﾞﾗｯｸｽﾘﾊﾞｰﾌﾞ/ﾍﾞｰｽﾏﾝ
TwinReverb/ProReverb/DeluxeReverb/Bassman
link　　　link2
Coast Music,Costa Mesa,California
left to right:Vibrolux-Reverb/Vibro-Champ/Pro-Reverb/Princeton-Reverb/Deluxe-Reverb
From a store full of amplifiers, it's easy to pick out the sharp ones. Fender always displays the tops in performance and appearance.Try them out;comparison proves Fender superiority.
FENDER PRO/REVERB AMP
Here is the professional amplifier that compliments a variety of jobs. Reverberation and Vibrato gives the player an amplifier compact in size yet having all the effects in one package. It is capable of excellent power and fidelity and employs two 12″Heavy Duty Custom Design Speakers giving excellent reproduction throughout the guitar range. “Tilt-back" legs assist in superior sound distribution.
The Pro/Reverb has the following controls for each of the normal and vibrato channels:two instrument inputs,bright switch, volume,treble and bass;plus reverb,speed and intensity controls for the reverb/vibrato channel.0n the back panel are located the AC outlet,ground switch,extractor-type fuse post,on-off switch,standby switch,speaker jack,extension speaker jack,jack for remote control vibrato foot switch and jack for remote control reverb foot switch supplied with the amplifier. Tubes:3-7025,2-12AT7, 1-12AX7(each dual purpose),2-6L6GC,1-GZ34(The dual purpose tubes make the Pro/Reverb the equivalent of a fifteen tube amplifier.)2-12″Heavy Duty Custom Design Speakers.Size:Height 19-1/2″,Width 26-1/2″,Depth 10″. RMS power output 40 watts;peak power output 88 watts. J.B.Lansing replacement speakers D-120F.
FENDER VIBROLUX/REVERB AMP
Big performance in a small package describes the vibrolux/Reverb.Built-in Reverb and vibrato plus two 10″heavy duty speakers make it ideal for club work and for recording. The circuit incorporates the latest control and audio features to make it the finest amp of its type in its price range.
An easy access front control panel includes separate volume,treble,bass controls and bright switches for each of the normal and vibrato channels,plus reverb, speed and intensity controls for the vibrato channel. The back panel includes AC plug,ground switch,extractor-type fuse post,AC on-off switch,speaker jack, extension speaker jack,jack for vibrato foot switch and jack for reverb foot switch supplied with the amp. Tubes:3-7025,2-12AT7,1-12AX7 (each dual purpose), 2-6L6GC and 1-GZ34.(The dual purpose tubes make the vibrolux/Reverb the equivalent of fifteen tubes.) Size: Height 18-1/2″,Width 25″,Depth 9-1/2″. RMS power output 35 watts;peak power output 77 watts. J.B. Lansing Replacement speakers D-110F.
FENDER DELUXE/REVERB AMP
Styling and advanced engineering make the Deluxe/ Reverb the first in its class. Built-in Reverb and vibrato plus its ample power give it outstanding performance,particularly for recording and small club work.
The Deluxe/Reverb employs the following features: two channels;normal and vibrato containing two volume controls,two treble controls,two bass controls,reverb,speed and intensity controls and a pilot light.The back panel includes:AC plug,ground switch,extractor-type fuse post,AC on-off switch, standby switch,speaker jack,extension speaker jack, jack for reverb foot switch and jack for vibrato foot switch. Tubes:3-7025,2-12AT7,1-12AX7(each dual purpose),2-6L6GC and 1-GZ34. (The dual purpose tubes make the Deluxe/Reverb the equivalent of a fifteen tube amp.)One 12″Custom Design Heavy Duty Speaker.Size:Height 17-1/2″,Depth 9-1/2″,Width 24-1/2″. RMS power output 20 watts;peak power output 44 watts.J.B.Lansing replacement speaker D-120F.
FENDER PRINCETON/REVERB AMP
A performance-proven favorite among students,studio operators and guitar teachers everywhere.The Princeton/Reverb includes built-in Reverb and vibrato plus an impressive list of features found only in more expensive amps. Compare it!
Its front panel includes:Two instrument inputs,volume,treble,bass,reverb,speed and intensity controls plus a pilot light. The back panel includes:AC outlet, AC on-off switch,ground switch,extractor-type fuse post,speaker jack,extension speaker jack,jack for reverb foot pedal and jack for vibrato foot pedal. 0ne 10″Custom-Design Heavy Duty Speaker. Size: Height 16″,Depth 5-1/2″,Width 16″. RMS power output 12 watts;peak power output 26 watts.
FENDER VIBRO/CHAMP AMP
Fender's Vibro-Champ was designed particularly for the student and the advanced or professional desiring a home“practice”amp. Its impressive sound,modem styling,plus built-in vibrato make it tops for these uses. Heavy duty components and construction will glve years of servlce.
The front panel includes:two instrument inputs,volume,treble,bass,speed and intensity controls,an on-off switch and pilot light. 0ne 8″Heavy Duty Special Design Speaker. Size:Width 17″,Height 14″,Depth 7-1/2″.RMS power output 5 watts;peak power output 11-1/2 watts.
Melodyland Theater,Anaheim,California
Left to right: Bassman/Super-Reverb/Dual-Showman/Showman/Bandmaster/Twin-Reverb
Fender Professional Amplifiers supply a theater of sound for instruments of every type. Distortionless balcony power is a“bilt-in" that gives satisfaction to every musician. Advanced circuitry gives assurance of long trouble-free performance and new styling gives good looks for years to come. The stage is yours when yours is Fender.
FENDER DUAL SHOWMAN AMP
Fender's popular DuaI Showman Amplifier,one of the world's most powerful amps,will fill a hall with unsurpassed musical instrument amplification. The amp is of the“piggyback" or dual unit design featuring two enclosed 15″J.B.Lansing Speakers in column form which produce unexcelled brilliance of tone. The speakers are mounted in a special design baffle making the Dual Showman distortion-free at very high volume with full tone reproduction. The chassis,or amplifier portion,may be top-mounted as shown,or used as a remote unit.
Fender's Dua1 Showman Amp features the following controls on the front panel:two inputs for each channel,separate bright switches,volume,treble,and bass ontrols;middle,speed and intensity controls for the vibrato channel.The back panel includes:AC outlet,ground switch,extractor-type fuse post,AC on-off switch,standby switch,speaker jack,extension speakerjack,and jack for the remote control vibrato foot switch supplied with the amp.
The Dual Showman is recommended for those who desire the ultimate in musical instrument amplification. Tubes used: 2-7027, 1-12AT7 and l-12AX7 (each dual purpose)，4-6L6GC, Silicon Rectifiers; (the dual purpose tubes make the Dual Showman the equivalent of a fourteen tube amplifie).Two 15″J.B.Lansing D-130F Speakers for two 15″ JBL D-140F Bass Speakers by special order).Size: Chassis unit: Height 8″,Width 24″,Depth 9-1/2″.Speaker unit:Height 45-1/2″,Width 30″,Depth 11-1/2″.RMS power output,85 watts;peak power output 187 watts.
FENDER DUAL SHOWMAN AMPLIFIER WITH REVERB
Fender's Dual Showman with built-in reverb enables the musician to obtain the exceptional Dual Showman performance with the additional feature of reverberation.This hall-filling amplifier will now present an even more desirable unit because of its new versatility.
FENDER SHOWMAN 15″AMP
Quality craftsmanship insures encore after encore with the Fender Showman Ampnfier. It contains all the features of the Dual Showman except that it is equipped with one J.B.Lansing 15″enclosed speaker. Widely considered to be one of the finest amplifiers available,it is recommended to those desiring widerange high-fidelity tone with high volume.
Tubes used:2-7025,1-12AT7 and l-12AX7 (each dual purpose),4-6L6GC,Silicon Rectifiers. The dual purpose tubes make the Showman the equivalent of a fourteen tube amplifier. 0ne 15″J.B.Lansing D-130F Speaker for one 15″D-140F JBL Speaker by special order).Size:Chassis unit; Height 8″,Depth 9-1/2″,Width 26″,Speaker unit;Height 24-1/2″,Width 36″,Depth 11-1/2″,RMS power output 85 watts;peak power output,187 watts.
FENDER BANDMASTER AMP
Keep your audience in the palm of your hand with the powerful performance of the Fender Bandmaster. The many professional features included make it one of the most popular in its price class. It is of“piggyback" or dual-unit design. Two 12″heavy-duty enclosed speakers are mounted in large individual specially- designed baffles. The special design of this enclosure greatly improves tone and volume without distortion, and permits,optimum performance of the speakers.
Fender's Bandmaster features the following controls on the front panel:Normal Channel;separate bass, treble,volume controls and bright switch,two instrument inputs. Vibrato Channel;separate bass,treble, volulne controls and bright switch,plus speed and intensity controls,two instrument inputs. Back panel; AC outlet,ground switch,extractor-type fuse post,AC on-off switch,standby switch,speaker jack,extension speaker jack, and jack for remote control vibrato foot switch supplied with the amp. The Bandmaster is recommended for those who wish fine instrument amplification at a moderate price. Tubes:2-7025,1-12AT7, and 1-12AX7(each dual purpose),2-6L6GC,Silicon Rectifiers.The dual purpose tubes make the Bandmaster the equivalent of a twelve tube amplifier. Size:Chassis unit:Height 8-1/2″,Width 24″,Depth 9-1/2″. Speaker unit:Height 40″,Width 29-1/2″,Depth 11-1/2″. Two 12″custom designed heavy duty speakers. RMS power output,40 watts;peak power output 88 watts.J.B.Lansing replacement speakers,D-120F.
FENDER BANDMASTER AMPLIFIER WITH REVERB
The Fender Bandmaster with built-in reverb will prove adaptable to practically any musical challenge. All the regular Bandmaster features including high power, enclosed 12″speakers and vibrato,pack a punch unmatched in the medium price range.
FENDER TWIN/REVERB AMP
Fender's Twin/Reverb Amp features flawless reproduction from its latest circuit advances. Modern styling spotlights prestige stage appearance. It is capable of extremely high distortionless power with wide tone range characteristics making it a favorite among topflight musicians. It is housed in the modern cabinet with black “Tolex" vinyl covering,and constructed for hard professional use. In addition,the Twin/Reverb has tilt-back legs enabling the sound to reach the farthest point in the room or hall in which it is being played.Sound distribution is also greatly assisted through the use of its two 12″heavy duty speakers.
Features of the Twin/Reverb include a convenient front control panel on which are located two inputs for each channel plus separate bright switches,volume, treble,middle,and bass controls for each channel; plus speed,depth and reverb controls for the reverb/ vibrato channel. 0n the back panel are located the AC outlet,ground switch,extractor-type fuse post,on-off switch,standby switch,speaker jack,extension speaker jack,jack for remote control vibrato foot switch and jack for remote control reverb foot switch supplied with the amplifier. The Twin/Reverb Amp is highly recommended where high fidelity sound is required at high volume and is one of the outstanding amplifiers on today's market. Tubes used:3-7025,2-12AT7 and 1-12AX7(each dual purpose),4-6L6GC,Silicon Rectifiers.The dual purpose tubes make the Twin/Reverb the equivalent of an eighteen tube amplifier. Two 12″ custom designed heavy duty speakers. Size:Height 20-1/2″,Width 26-1/2″,Depth 9-1/2″.RMS power output, 85 watts;Reak power output,187 watts. J.B.Lansing replacement speakers,D-120F.
FENDER BASSMAN AMP
Rugged and dependable! These words best describe the Fender Bassman Amp. The popular column arrangement gives the best possible sound dispersion. The Bassman incorporates two enclosed speakers with a separate amplifier chassis unit.The two enclosed 12″ heavy duty custom designed speakers,with their individual special design baffles,make the Bassman distortion-free,allowing the player to use his full bass notes and ample volume,Another Bassman feature is the incorporation of dual channels;one a Bass Channel,and the other Normal which may be used with instruments other than bass.
The Bassman has become a favorite with bassists throughout the world and is recommended to those players who desire the finest in electric bass,bass guitar and guitar amplification. Front panel controls include:Bass channel:two instrument inputs,deep switch,separate bass,treble and volume. Normal channel:two instrument inputs,bright switch,separate bass,treble and volume. Back panel:AC outlet, AC on-off switch,standby switch,speaker jack and extension speaker jack. Tubes:3-7025，,1-12AT7(each dual purpose),2-6L6GC,Silicon Rectifiers.The dual purpose tubes make the Bassman the equivalent of a twelve tube amplifier. Size:Chassis unit:Height 8-1/2″, Width 22″,Depth 9-1/2″.Speaker unit:Height 40″, Width 29-1/2″,Depth 11-1/2″.RMS power output,50 watts;peak power output 110 watts.
FENDER SUPER/REVERB AMPLIFIER
Big amp sound and convenient portability combine to make the Super/Reverb one of the all-time Fender super-stars. It's one of the most frequently used amplifiers in studios and clubs throughout the world. Both reverb and vibrato are built-in to meet all playing requirements. It features the new modern Fender Professional Amplifier cabinet styling and vinyl “Tolex" covering and is recommended for use for all amplified instruments.
Controls are mounted on the convenient front panel: Normal channel;two instrument inputs,bright switch, volume,treble and bass controls,vibrato channel;two instrument inputs,volume,treble,middle,bass,reverb, speed and intensity controls and bright switch. Back panel;AC outlet,ground switch,speaker jack,extension speaker jack,extractor-type fuse post,AC on-off switch,standby switch,jack for vibrato foot pedal and jack for reverb foot pedal supplied with the amplifier. Tubes:3-7025,1-12AX7 and 2-12AT7 (each dual purpose),2-6L6GC,1-GZ34 (the dual purpose tubes make the Super/Reverb the equivalent of a fifteen tube amplifier).4-10″custom designed Heavy Duty speakers. Size:Height 25-1/2″,Width 25-1/2″,Depth 9-1/2″.RMS power output,40 watts;peak power output,88 watts. J.B.Lansing replacement speakers D-110F.
FENDER AMP STAND
Fender Amplifier Stands are available to accommodate all large amps including Public Address columns. These attractive stands tilt the amplifier backward at various degrees in order to loft the sound to the far corners of any club or hall. The stand is equipped with wheels on the rear legs to allow easy movement. It is easy to install,extremely sturdy and heavily chromed to retain its handsome appearance. This unit is also available as an accessory.
FENDER FUZZ-WAH
Only Fender has produced a unit so far out! Push the pedal up and down...the result is fuzz that really is. Side to side and the pedal produces a Wild wah effect. Combine both actions and both effects run rampant. When utilizing both channels of a two-channel amplifier,one channel will control the volume and tone of the instrument while the other controls the volume and tone of either fuzz,wah,or both.It is therefore possible to obtain any degree or variation of both effects. Wild!
The Fender Booth 1968Teenage Fair,Hollywood,California
left to right:P.A.Column/Solid-State Amps;Deluxe-Reverb/Pro-Reverb/Super-Reverb/Bassman/Twin-Reverb/Vibrolux-Reverb
Fender dazzles the musical world with a solid state“rock-in". These solid-state amplifiers,including Bassman,Vibrolux/Reverb,Deluxe/Reverb,Twin/Reverb.Pro Reverb,and Super/Reverb are the heavy-duty Performers that lock on to today’s sounds.When you want the finest solid state-ment,select one of Fender's solid state amps. Join the Fender sound revolution！
FENDER SOLID STATE PRO/REVERB AMP
Smooth sounds...powerful sounds...combine with portability to make the Solid State Pro/Reverb ideal for the traveling musician. New solid state styling assures a modern look for years to come and built-in reverb and vibrato give it those “extras”to handle the right job at the right time.
Front panel features include:Normal channel:two instrument inputs,bright switch,volume,treble and bass controls.vibrato channel:two instrument inputs, ♭right switch,volume,style treble,bass,reverb,vibrato speed and vibrato intensity controls. The style control gives tone settings of “Pop-Normal-CW/RR”in order to suit each style of playing.
Back panel features include:on-off-ground switch,AC outlet,circuit breaker,jack for remote vibrato foot switch,jack for remote reverb foot switch,speaker jack,extension speaker jack,extractor-type fuse post. A double foot switch is supplied with the amplifier. Speakers:two 12″heavy duty special design. NEW POWER RATINGS:RMS power, 56 watts;EIA music power,95 watts ;Peak power,190 watts. Size:Height 32-1/2″,Width 19-1/2″,Depth 10-1/2″.
FENDER SOLID STATE BASSMAN AMP
Built for high-powered big beat sound...the solid state Bassman sounds-off with an undistorted 105 watts RMS output,Utilizing three extremely heavyduty special design 12″speakers,enables the bassist to obtain very high volume with his lowest notes. A tough,rugged bass amp that takes on all comers!
The Bassman features a single channel with two instrument inputs,volume,treble and bass controls.The treble and bass controls allow both boost and cut of their respective functions. In addition,a style control gives the player four separate positions including two positions of bass boost,guitar normal and guitar bright.An overload light signals the player when the speakers are being driven past the safe point. The pilot light indicates power on or off. The back panel includes the on-off-ground switch, AC outlet,circuit breaker,speaker jack,extension speaker jack and extractor-type fuse post. Size:Chassis Unit;Height 6-1/2″,Width 13-1/4″,Depth 10″.Speaker Unit;Height 40″,Width 30″,Depth.11-1/2″.NEW POWER RATINGS: RMS power,105 watts;EIA music power,175 watts; EIA peak power,350 watts.
FENDER SOLID STATE TWIN/REVERB AMP
Fender's transistorized Twin/Reverb is a single-unit, column-type model with built-in reverb and vibrato. Its new styling and circuitry make it extremely attractive on stage as well as high in performance. A side handle permits easy carrying and weight has been cut considerably by the use of silicon-type transistors and a single power transformer. The output stage is cooled by convection through a specially designed front panel.
Front panel includes:Normal channel:two instrument inputs,bright switch,style,volume,treble and bass controls.vibrato channel:two instrument inputs, bright switch,style,volume,treble,bass,vibrato speed,vibrato intensity and reverb controls. The style switch gives tone settings of“Pop-Normal-CW/RR”in order to suit each style of playing. Back panel includes:on-off-ground switch,AC outlet,circuit breaker,jack for remote vibrato foot switch,jack for remote reverb foot switch,speaker jack,extension speaker jack and extractor-type fuse post. Speakers: 2-12″heavy duty custom design. Size:Height 32″, Depth 10-1/2″,Width 19″.NEW POWER RATINGS:RMS power,105 watts;EIA music power,175 watts;EIA peak power,350 watts.
FENDER SOLID STATE VIBROLUX/REVERB AMP
An ideal compact amplifier for clubs and studios. High power capabilities include:built-in reverb and vibrato.
Front panel includes:Normal channel:two instrument inputs,bright switch,volume,treble and bass controls. vibrato channel:two instrument inputs,bright switch, volume,treble,bass,vibrato speed,vibrato intensity and reverb controls. Back panel includes:on-off-ground switch,AC outlet,circuit breaker,jack for remote vibrato foot switch,jack for remote reverb foot switch,speaker jack,extension speaker jack,extractor-type fuse post. Speakers:2-10″heavy duty custom design. Size:Height 31-1/4″,Width 18-1/4″,Depth 10-1/2″. NEW POWER RATINGS:RMS power,42 watts;EIA music power,60 watts;EIA peak power,120 watts.
FENDER SOLID STATE DELUXE/REVERB AMP
The Deluxe/Reverb is Fender's smallest solid-state amp...in size only. Its big power sound must be heard to be appreciated. It has built-in reverb and vibrato,perfect for small clubs,recording and home use. Professional guitarists find that this high performance amplifier more than fulfills their demanding requirements.
Front panel includes:Normal channel:two instrument inputs,volume,treble,bass controls and bright switch. vibrato channel:two instrument inputs,bright switch, volume,treble,bass,vibrato speed,vibrato intensity and reverb controls.
Back panel includes:on-off-ground switch,AC outlet, circuit breaker,jack for remote vibrato foot switch, jack for remote reverb foot switch,speaker jack,extension speaker jack and extractor-type fuse post. Speaker:1-12″heavy duty custom design. Size:Height 19″,Width 17-1/2″,Depth 10″.NEW POWER RATINGS: RMS power,32 watts;EIA music power,50 watts;EIA peak power,100 watts.
FENDER SOLID STATE SUPER/REVERB AMP
This new solid state Super Reverb Amp produces ample power without distortion,suitable for practically any stage. Styled for show...powered for“go”!
Front panel features include:Normal channel:two instrument inputs,bright switch,volume,treble and bass controls.vibrato channel:two instrument inputs, bright switch,style,volume,treble,bass,reverb,vibrato speed and vibrato intensity controls. The style switch gives tone settings of“Pop-Normal-CW/RR″in order to suit each style of playing.
Back panel includes:on-off-ground switch,AC outlet, circuit breaker,jack for vibrato to remote foot switch, jack for remote reverb foot switch,speaker jack,extension speaker jack and extractor-type fuse post. A double foot switch is supplied with each amplifier. Speakers:four 10″heavy duty special design. NEW POWER RATINGS:RMS power, 56watts;EIA music power,95 watts;EIA peak power,190 watts. Size: Height 33-1/2″,Width 22-1/2″,Depth 10-1/2″.
